SB265 Alloy Round Bar TI4AL4V 8mm 10mm Gr5 304 Stainless Steel Bar TC3 TC4

  • 1
  • 2

Brand Name : TISCO

Model Number : 201 304 316 317 321 310 309 410 420

Certification : SGS ISO ROHS

Place of Origin : Mainland China

MOQ : 100KG

Price : 500-1000 USD PER TON

Payment Terms : L/C, T/T, Western Union

Supply Ability : 800TONS PER MONTH

Delivery Time : 5-10Days after confirming order

Packaging Details : Standard Waterproof Package

Product Name : Titanium Bar

Material : gr1, gr2, gr3,gr4, gr5,gr7, gr9, gr10

Testing : third party inspection available

Processing service : Bending cutting welding punching

Trading term : CIF CFR FOB EXW

Ti : 99.9%

Application : Industrial,Medical,industrial and medical,electroplating equipment,Mechanical equipment

MOQ : 100KGS

Contact Now

ASTMF136 Gr5 TI4AL4V 5mm/8mm/10mm/12mm Titanium Alloy Rods Bar

The titanium tube is light in weight, high in strength and superior in mechanical properties. It is widely used in heat exchange equipment, such as tube and tube heat exchangers, coil heat exchangers, serpentine tube heat exchangers, condensers, evaporators and transportation pipelines. Many nuclear power industries use titanium tubes as standard tubes for their units.

Product Description

Description Titanium bar/titanium rod
Material

Gr1, Gr2, Gr3,Gr4,Gr5, Gr7, Gr6,Gr9, Gr11, Gr12 ,Gr16, Gr17,Gr25

TA0,TA1,TA2,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4
Standard ASTM B265,ASME SB265,DIN17851,TiA16Zr5Mo1.5,JIS4100-2007,GB3461-2007
MOQ 100kgs
Equepment used CNC lathes, Milling machine, Machining Center,Thread rolling machine Magnetic needle polishing machine
Package Standard export package,suit for all kinds of transport ,or as required.
Application

1.Based on High intensity,titanium products tensile strength can be up to 180Kg/mm².

2.Titanium and titanium alloy in aviation industry, is called "space metal"; In addition,

in the shipbuilding industry, chemical industry, manufacturing machinery parts,

telecommunications equipment, hard alloy, etc have increasingly extensive application

3.In addition, because of the titanium alloy with the human body has very good compatibility,

so the titanium alloy can also be artificial bone.

Product Details

SB265 Alloy Round Bar TI4AL4V 8mm 10mm Gr5 304 Stainless Steel Bar TC3 TC4

SB265 Alloy Round Bar TI4AL4V 8mm 10mm Gr5 304 Stainless Steel Bar TC3 TC4

Chemical Composition

Grade chemical composition, weight percent (%)
C H O N Fe Al V Pd Ni Mo Ti
(≤) (≤) (≤) (≤) (≤) - - - - - bal
GR1 0.08 0.015 0.18 0.03 0.2 - - - - - bal
GR2 0.08 0.015 0.25 0.03 0.3 - - - - - bal
GR4 0.08 0.015 0.25 0.03 0.3 - - - - - bal
GR5 0.08 0.015 0.2 0.05 0.4 5.5~6.75 3.5~4.5 - - - bal
GR7 0.08 0.015 0.25 0.03 0.3 - - 0.12~0.25 0.12~0.25 - bal
GR9 0.08 0.015 0.15 0.03 0.25 2.5~3.5 2.5~3.5 - - - bal
GR11 0.08 0.15 0.18 0.03 0.2 - - 0.12~0.25 - - bal
GR12 0.08 0.15 0.25 0.03 0.3 - - - 0.6~0.9 0.2~0.4 bal
GR23 0.08 0.125 0.13 0.03 0.25 5.5~6.5 3.5~4.5 - - - bal

Physical Properties

Grade Physical properties
Tensile strength Yield strength Elongation in 4D Reduction of Area
Min Min (0.2%, offset) Min (%) Min (%)
ksi MPa ksi MPa
Gr1 35 240 20 138 24 30
Gr2 50 345 40 275 20 30
Gr4 80 550 70 483 15 25
Gr5 130 895 120 828 10 25
Gr7 50 345 40 275 20 30
Gr9 90 620 70 483 15 25
Gr12 70 483 50 345 18 25
Gr23 120 828 110 759 10 15


Packaging & Shipping
SB265 Alloy Round Bar TI4AL4V 8mm 10mm Gr5 304 Stainless Steel Bar TC3 TC4

Certification


SB265 Alloy Round Bar TI4AL4V 8mm 10mm Gr5 304 Stainless Steel Bar TC3 TC4

FAQ
Q1: ARE YOU FACTORY OR TRADER?

A1: Our company is a cold rolling manufacturer of magnetic stainless steel coil since 2012. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.


Q2: WHICH MATERIAL/PRODUCTS YOU CAN PROVIDE?

A2: Stainless Steel Coils / Strips, Stainless Steel Sheets / Plates, Stainless Steel Circles / Discs, Decorative Stainless Steel Sheets.


Q3: HOW TO GET A SAMPLE?

A3: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.


Q4: HOW TO VISIT YOUR FACTORY?

A4: Most of the main cities have flights to Wuxi; you can take flight to Wuxi Shuofang International Airport.

If you come from Shanghai, it will take 2 hours by flight (every day 5 flights).
If you come from Hongkong, it will take 1 hour by flight (every day 1 flight around noon time).
